Description
- Power Consumption: 1,050KW max @ 132VAC
- Rated Tube Potential: 70kVp +/- 7% (Single phase, self rectifying).
- Rated Tube Current: 8mA +/- 15% @ 120VAC
- Exposure Time Range: 0.03 to 3.00sec., in steps of 0.01sec. Plus,
27 pre-set exposure times, with automatic main voltage
compensation.
- Minimum Focal Spot to Skin Distance: 200mm (8″)
- Radiation Leakage @ 1 m. Less than 50mR/h (Technical Factors:
70kVp, 8 mA, 1s.).
- Focal Spot: 0.8 x 0.8mm
- Total Filtration: 2mm. Al eq.
